ElliptiGO 8S Owner's Manual page 21

The Riding Position
When in the riding position, the column extends vertically up from the
base, the steering extender is set to the correct depth in the column,
the bottom of the collar is flush with the top flange of the base and set
to the "LOCK" position, and all quick release levers are firmly closed.
The correct steering extender depth is reached when the handlebar
height is the most comfortable for the rider when riding and the "MAX
EXTENSION" line is not visible above the base. This height is usually set
so that the rider stands tall when riding with little to no weight on his/
her hands or wrists.
To place the folding steering column into the riding position,
follow these steps:
1. Place the bike on the kickstand.
2. Open both collar quick releases.
3. Slide the collar towards the handlebars along the steering
column to clear the pivot.
4. Lift the steering column up into the vertical position so
that it is in-line with the base.
