3.4

Connecting the Serial Port (Optional)

Serial access
Requirements for using
the serial access
Procedure
3EC 17059 ABAA TCZZA Ed. 01
Like most routers the STPro carries a serial port on its back panel,
featuring access from a remote host via a modem connection or
local access from a terminal.
For access via the serial port, you must have the following:
A serial cable
"
An ASCII terminal (VT100) or a workstation/PC with ASCII
"
terminal emulation or emulation application for local
configuration via the CLI
or
A POTS or ISDN modem for remote configuration of the
"
STPro via the CLI.
Proceed as follows to connect the STPro serial port:
Step Action
1 Determine the serial port on the STPro back panel.
See appendix B for more information.
2 Connect the serial cable to the STPro serial port.
3 Connect the other end of the serial cable to the serial
interface of the (emulated) ASCII terminal or modem.
3 Wiring Guide - DSL, Power and Console
37 / 238
