AppendixB Speed Touch Specifications
B.5

Power Supply Adapter

Power adapter use
Power adapter models
Output specifications
222 / 238
The STPro is equipped with one of the following pluggable power
supply adapters listed in the table.
Due to the special characteristics of the output class II AC adaptor,
use only the AULT, Incorporated types, or equivalents, listed in
the table.
Model AC/DC
Reference
US model 120V/9V
UK/Sing model 230V/9V
ROW(*) model 230V/9V
Australia model 240V/9V
Korea Model 220V/9V
(*) Rest Of the World (ROW)
The supplied adapter has the following output specifications:
9V /1A unregulated output voltage
"
DC
Maximum 860 mV
"
Maximum 1A output current
"
Limited power source (according to IEC/EN 60950,
"
sub clause 2.11 and UL1950).
Note: Do not use power adapter types with other specifications (e.g. from other
Alcatel Speed Touch
Plugtype
North America wall
plug
UK wall plug
Euro wall plug
Australia wall plug
Korea wall plug
ripple voltage
eff
products) !
AULT, Inc. Model
(or equivalent)
P48-091000-Axxxx
F48-091000-Axxxx
D48-091000-Axxxx
E48-091000-Axxxx
Q48-091000-Axxxx
3EC 17059 ABAA TCZZA Ed. 01
