10.2.4

Explicit Assignment Mechanism

Explicit assignment
Explicit assignment
example
Note
3EC 17059 ABAA TCZZA Ed. 01
In the case of a remote access server which is not
RFC1577/RFC2225 compliant, it will not respond to InATMARP
requests.
As a consequence, the STPro can not retrieve the remote IP
address to assign the CIP PVC to the CIP member.
Therefore you must explicit assign a remote IP address to the CIP
PVC.
The default configuration of the STPro is an example of the
explicit assignment of a CIP PVC to a CIP member:
In the 'CIP Interfaces' table, the CIP member is configured as
follows:
In the 'CIP Connections' table, the remote IP address is statically
configured:
Consequently, CIPPVC1 is explicitly assigned to cip0.
Both local and remote IP addresses must fall within the same IP
network and IP subnetwork, according the LIS parameters.
10 Configuration and Use - CIP & IP Routing
103 / 238
