The 'PPP
Configuration' table
'PPP Configuration'
table components
3EC 17059 ABAA TCZZA Ed. 01
The following figure shows the 'PPP Configuration' table:
Field Description
Name Indicates the PPP phonebook entry name for the PPP entry.
Encap Indicates the applied encapsulation method for PPP frames in
the VC.
The STPro supports both the VC MUX method (default) and
the LLC/SNAP method.
Mode Indicates whether the PPP entry is configured for:
Always on" connectivity
Dial in" connectivity
Dial on Demand" connectivity.
See section 9.4.4 for more information.
State Indicates the active state of the PPP session.
It can take following values:
Status Allows to change the state of Always on PPP entries:
On: The always on PPP connection is enabled.
Off: The always on PPP connection is disabled.
9 Configuration and Use - PPP & IP Routing
Value Description
Up The PPP session is opened and active.
Down The PPP session is closed, the PPP
connection is idle.
Trying
The PPP session is trying to reach the
active state.
