Command Line Interface (CLI)

All configuration parameters are set using the Command Line Interface (CLI). The CLI is
accessed through the network, using a telnet client, or through the serial port, or data modem (for
models with internal modem option) using a terminal client. In iControl clusters, all remote
iControls can be configured and managed through the connection to the Master iControl. It is
also possible to access, configure and control any Expansion iControls directly.
Open a telnet client and point it to the current IP Address of the iControl.
(Factory Default is 192.168.0.254, telnet Port 23)
Connect to the Serial port or via PSTN connection to the modem.
(Factory Default is 115200,8,n,1)
Upon connection, press Enter, and then enter the username and password when prompted.
(Factory Default for username and password is admin)

Setting the IP Address

iControls come with factory default IP address 192.168.0.254.
There are three techniques to setting the IP address of the iControl:
To configure the mode to set the IP address, access the iControl's command line interface (CLI)
and use the set ipmode command as indicated below.
1. Terminal Client software via Telnet, Serial, Modem.
2. Automatically from a DHCP Server
3. ARP / Ping (factory default)
