iControl Manual
LED INDICATORS
There are two LED indicators located on the front panel. Their function is as follows:
Self Test (Green):
When illuminated, the surge suppression circuitry is functioning correctly.
Power (Red):
When illuminated, the iControl is connected to a live wall or floor outlet.
WEB SERVER
The iControl web interface provides the easiest means of operating the outlets and monitoring
the current status of the units. One or
more outlets can be simultaneously
controlled with a few mouse clicks. In
cluster configurations, all 128 outlets
can be managed from the web pages.
The interface is divided into three
sections: Header, Control, and Status.
Each user will only be able to view
and control the outlets, devices, and
groups that have been assigned to that
particular user.
Header
The header identifies the iControl currently being accessed. If multiple iControls are deployed in
a cluster configuration, this will be the master iControl.
The header allows the selection of various status views. To select an individual iControl, or
predefined group of outlets, click on the one of the two dropdown lists. To select the global view,
click on Global. To see the status of the AutoPing feature, click on AutoPing.
10
