SPECIFICATIONS

Load Rating: 15/20 Amps at 120 Volts (SX-1115ip-X/SX-1120ip-X)
Power Requirement (no load): 4 Watts
Surge Let-through Voltage (6000 Volt surge): 0 Volts
UL 1449 Adjunct Classification Test Results: 1000 surges, 6000 Volts, 3000 Amps, B3 pulse; measured
suppressed voltage, 170 Volts; no failures
Federal Guidelines: Grade A, Class 1, Mode 1 (CID A-A-55818)
EMI/RFI Filter, Normal Mode (50 Ohm load): 40 dB @ 100 KHz, 50dB @ 300 KHz, 50 dB @ 3 MHz, 50 dB @
30 MHz
EMI/RFI Filter, Common Mode (50 Ohm load): 18dB @ 300 KHz, 30 dB @ 1 MHz, 50 dB @ 5 MHz, 50 dB @
20 MHz
Maximum Applied Surge Voltage: 6000 Volts *
Maximum Applied Surge Current: Unlimited (due to current limiting) *
Maximum Applied Surge Energy: Unlimited (due to current limiting) *
Endurance (C62.41-1991 category B3 pulses): 1 KV > 500,000; 3 KV > 10,000; 6 KV > 1000
Undervoltage Shutdown: Adjustable from 90 Volts to 105 Volts
Overvoltage Shutdown: Adjustable from 135 Volts to 150 Volts
Network Port: 10/100 Base T Ethernet connection on Female RJ-45
Modem Port: V.92 and below on Female RJ-11 (for models with internal modem option)
Serial Port: 115,200 bps on Female 9-pin D-subminiature
Dimensions: 19" W x 12.25" D x 1.75" H (Single Rack Space)
Weight: 13.0 lb.
Temperature Range: 5C to 35C
Humidity Range: 0% to 95% R.H. Non-condensing
Agency Listings: ETL and cETL (UL 1449, 3rd Edition; CSA C22.2 No.8-M1986, R2000)
* 1.2 x 50 microsecond industry standard combination wave surge as per IEEE C62.41
*CAUTION: Do not install this device if there is not at least 10 meters (30 feet) or more
between the electrical outlet and the electrical service panel.
