Autoping Commands; Event Commands - SurgeX SX-1115ip-X User Manual

iControl Manual

Autoping Commands

Command
get autoping <1‐16>
set autoping <1‐16> ipaddress <dotted decimal>
set autoping <1‐16> action <action>
set autoping <1‐16> frequency <1‐999>
set autoping <1‐16> count <1‐99>
set autoping <1‐16> device <name/#1‐16> outlet <1‐8>
set autoping <1‐16> group <name>

Event Commands

Command
get events
get event <eventname>
add event <eventname>
del event <eventname>
ren event <eventname> <new name>
set event <eventname> year <2007 – 2050>
Description
Returns the settings and state of the selected autoping.
Set the IP address of the selected autoping in dotted
decimal.
Set the action of the selected autoping. On-Follow, On-
Latch, Off-Follow, Off-Latch, Cycle, Cycle-Once, or
None.
Set the frequency of the selected autoping in seconds.
Set the number of failures the selected autoping requires
before it triggers its action.
Assign an autoping to either a device/outlet or group.
Each autoping can be assigned to one or the other.
Description
Returns a list of all pending events.
Returns the details of the selected event.
Creates a new event. Up to 16 events can be created.
The default time and date will be the time and date that the event is
added. The default action is none, and the default repeat is never.
Deletes the selected event.
Renames the event.
Sets the year of the event.
20
Admin Fact Def
Yes
Yes 0.0.0.0
Yes None
Yes 10
Yes 3
Yes
Yes
Admin Fact Def
Yes
Yes
Yes
Yes
Yes
Yes
