iControl Manual

COMMAND LINE INTERFACE (CLI) PROTOCOL

The Command Line Interface provides complete setup of all functions of the iControl. The CLI may be accessed either via the
network interface using Telnet, or via the modem (for models with internal modem option) or serial port using a terminal emulator
program. Some commands of the CLI require administrative rights; these are indicated in the following tables.

Outlet Commands

Command
get outlets
get outlet <1‐8>
set outlet <1‐8> <on/off/cycle>
get device <#1‐#16/devname> outlet <1‐8>
set device <#1‐#16/devname> outlet <1‐8> <on/off/cycle>
set device <#1‐#16/devname> outlet <1‐8> name <name>
get device <#1‐#16/devname> outlet <1‐8> initial.state
set device <#1‐#16/devname> outlet <1‐8> initial.state
<on/off/last>
Description
Returns the status of ALL the outlets the user has rights to.
Displays all devices and outlets in a cluster configuration.
Returns the status of the iControl. This command is for
iControls not used in a cluster configuration. If used in a
cluster, it is the same as device #1. The user must have
rights to the selected outlet.
Sets the selected outlet to the selected state. The user must
have rights to the selected outlet. This command is for
iControls not used in a cluster configuration. If used in a
cluster, it is the same as device #1.
Returns the status of the selected outlet on the selected
iControl. Device is either the number of the device <#1 to
#16> or the name of the device, as set. Number sign (#)
required. The user must have rights to the selected outlet.
Sets the selected outlet on the selected iControl to the
selected state. The user must have rights to the selected
outlet.
Sets the name of the selected outlet of the selected iControl.
20 characters max.
Get or set the initial state of the selected outlet of the
currently selected iControl. Initial state is the condition of
the outlet when the iControl is powered up.
14
Admin Fact Def
No
No
No
No
No
Yes Outlet <#>
Yes Last
