Initial Set-Up; Setup And Control Utility (Scu) - SurgeX SX-1115ip-X User Manual

iControl Manual

INITIAL SET-UP

Setup and Control Utility (SCU)

The iControl Setup and Control Utility (SCU) utility provides the easiest means to find and
configure your iControl for use. The SCU can:
1. Automatically discover multiple iControls on a local network.
2. Add additional iControls not on the local network.
3. Download existing configurations from installed iControls.
4. Save existing configurations for later use or as backup.
5. Open saved configurations for change management.
6. Clone saved configurations for replication of similar configurations in multiple iControls.
7. Upload modified configurations to iControls.
8. Control outlets on one or more iControls throughout the network.
The iControl Setup and Control utility is available on the iControl CD or on the SurgeX website
at http://www.surgex.com
Note: The Setup and Control Utility only operates with iControls attached to the network.
iControls in a cluster configuration can be configured using the setup and control utility, if they
are attached to the network.
5
