iControl Manual

SNMP

Up to four SNMP managers can be set. Each manager will receive Trap notifications for outlet
changes, autoping, voltage alarms, and current alarms. Set the SNMP manager IP addresses
using the set snmp <n> ipaddress <dotted decimal> command. Enable or Disable SNMP for
any manager with the set snmp <n> enable <yes/no> command. Also see
"iControl q110630.285.mib" for more information.
The iControl also supports the following elements of MIB-II:
mgmt [1.3.6.1.2]
|
-> [ 1] -BR- mib-2
|
-> [ 1] -BR- system
|
-> [ 1] *RO* DisplayString
-> [ 2] *RO* OBJECT IDENTIFIER
-> [ 3] *RO* TimeTicks
-> [ 4] *RW* DisplayString
-> [ 5] *RW* DisplayString
-> [ 6] *RW* DisplayString
-> [ 7] *RO* INTEGER

FIRMWARE UPGRADES

The iControl can be upgraded via the network if the upload feature has been enabled using the
set upload enable yes command on the console interface. To upgrade the iControl, download the
latest version of the firmware and upgrade utility from the SurgeX website.
http://www.surgex.com

FRONT PANEL RESET BUTTON

The recessed reset pushbutton located on the front panel below the Self Test LED performs two
functions: CPU Reboot and Password Reset.
Pressing the reset button once quickly will reboot the iControl's CPU. Outlet states are not
affected.
Holding the reset button on the front panel of the iControl for 5 seconds or longer will initiate a
password recovery mode. Once the reset button is released, the user has 30 seconds to log in to
the CLI using the username admin and password admin. Upon accessing the CLI, change the
username and password for User 1 as desired.
sysDescr
sysObjectID
sysUpTime
sysContact Truncated to 128 Char
sysName Truncated to 128 Char
sysLocation Truncated to 128 Char
sysServices
29
