ADP1055-EVALZ User Guide
Qty. Reference Value
1 R4 10K
1 R5 0.001
1 R7 2
1 R8 10K
1 R9 0.001
1 R10 10k
1 R11 10K
1 R22 2
1 R23 10K
1 R24 2
1 R31 10K
1 R52 10
1 R53 0
1 R54 0
1 R58
1 R59
1 R60
1 R61
1 R62 0
1 R63 205
1 R64
1 R65 100
1 R66
1 R67 100
1 R68 0
1 R69
1 R70
1 R76 19.1k
1 R77 10k
1 R116 0
1 R117 10
1 R118
1 R119
1 R122 10k
1 R123
1 R124
1 R125
1 R126
1 R151 10
1 R152 10
1 R153 4.75K
1 R159 1
1 R160 1
Description
RES 10 kΩ 1/ 4 W 1% SMD
RES 0.001 Ω 21% SMD
RES 2.00 Ω 1/8 W 1% SMD
RES 10 kΩ ¼ W 1% SMD
RES 0.001 Ω 2 W 1% SMD
RES 10.0 kΩ 1/8 W 1% SMD
RES 10.0 kΩ 1/8 W 1% SMD
RES 2.00 Ω 1/8 W 1% SMD
RES 10 kΩ ¼ W 1% SMD
RES 2.00 Ω 1/8 W 1% SMD
RES 10 kΩ ¼ W 1% SMD
SMD RES 10 Ω ¼ W 5%
RES 0.0 Ω 1/8 W JUMP SMD
RES 0.0 Ω 1/8 W JUMP SMD
SHORTPIN
SMD RES 0 Ω 3/4 W 5%
SHORTPIN
SHORTPIN
RES 0.0 Ω 1/8 W JUMPER SMD
RES 205 Ω 1/8 W 5% SMD
SHORTPIN
RES 100 Ω 1/8 W 1% SMD
SHORTPIN
RES 100 Ω 1/8 W 1% SMD
RES 0.0 Ω 3/4 W 1% SMD
SHORTPIN
SHORTPIN
RES 19.1 kΩ 1/8 W 1% SMD
RES 10 kΩ 1/8 W 1% SMD
SMD RES 0 Ω 3/4 W 5%
SMD RES 10 Ω 1/4 W 5%
SHORTPIN
SHORTPIN
RES 10.0 KΩ 1/2 W 1% SMD
SHORTPIN
SHORTPIN
SHORTPIN
SHORTPIN
RES 0.0 Ω 1/8 W 5% SMD
RES 10 Ω 1/8 W 1% SMD
RES 4.75 kΩ 1/4 W 1% SMD
RES 1.0 Ω 1/4 W 1% SMD
RES 1.0 Ω 1/4 W 1% SMD
Rev. B | Page 41 of 43
Manufacturer Part Number
Stackpole RNCP0805FTD10K0
Bourns Inc CRF2512-FV-R001ELF
Yageo RC0805FR-072RL
Stackpole RNCP0805FTD10K0
Bourns, Inc CRF2512-FV-R001ELF
Yageo RC0805FR-0710KL
Yageo 311-10.0KCRCT-ND
Yageo RC0805FR-072RL
Stackpole RNCP0805FTD10K0
Yageo RC0805FR-072RL
Stackpole RNCP0805FTD10K0
Stackpole RNCP0805FTD10R0
Yageo RC0805FR-070RL
Yageo RC0805FR-070RL
Vishay/Dale 311-1.00CRCT-ND
Yageo RC0805JR-070RL
Yageo RC0805JR-07100RL
Yageo 311-100CRCT-ND
Yageo 311-100CRCT-ND
Vishay CRCW20100000Z0EF
Yageo 311-100CRCT-ND
Yageo 311-100CRCT-ND
Stackpole 311-1.00CRCT-ND
Stackpole RNCP0805FTD10R0
Stackpole RNCP1206FTD10K0
Yageo RC0805JR-070RL
Yageo RC0805FR-077K15L
Vishay/Dale CRCW12064K75FKEA
Stackpole CSR0805FK1R00
Stackpole CSR0805FK1R00
UG-710
