Analog Devices ADP1055-EVALZ User Manual page 40

UG-710
Qty. Reference Value
1 C137 4.7 µF
1 C138 0.1 µF
1 C141 10 µF
1 C189 1000 pF
1 C192 33 nF
1 D_Q39
1 D1
1 D5
1 D6 LED Green
1 D7
1 D8 LED Green
1 D16
1 D62
1 D75
1 D76
1 G_Q23
1 G_Q30
1 G_Q34
1 G_Q38
1 G_Q40
1 JP1 VIN+
1 JP2 VIN−
1 J1 BNC/R
1 J4 CON16
1 J5 CON30
1 J6 HDR1X4
1 J7 HDR1X4
1 J11 VOUT+
1 J12 VOUT−
1 L8
1 L10 1 µH
1 QA
1 QB
1 QC
1 QD
1 Q12
1 Q23
1 Q30
1 Q34
1 Q38
1 Q40
1 R1 2
1 R3 30.1k
Description
CAP CER 4.7 µF 50 V 10% X7R SMD
CAP CER 0.1 µF 25 V 10% X7R SMD
CAP CER 10 µF 25 V 10% X7R
CAP 1000 pF 50 V 10% X7R SMD
CAP CERAMIC 0.033 µF 100 V 5% NPO SMD
PC TEST POINT MINI SMD
LED SUPER RED CLEAR 75 MA 1.7 V SMD
DIODES POWER SWITCHING 120 V 400 mA
LED HI EFF RED CLEAR SMD
DIODES POWER SWITCHING 120 V 400 mA
LED HI EFF RED CLEAR SMD
DIODE SCHOTTKY 40 V 1A SMD
DIODE SCHOTTKY 40 V 1A SMD
DIODE ARRAY 100 V 300 mA
DIODE ARRAY 100 V 300 mA
PC TEST POINT MINI SMD
PC TEST POINT MINI SMD
PC TEST POINT MINI SMD
PC TEST POINT MINI SMD
PC TEST POINT MINI SMD
CONN JACK BANANA UNINS PANEL MOU
CONN JACK BANANA UNINS PANEL MOU
CONN JACK VERTICAL PCMNT GOLD
CONN HEADER BRKWAY 0.100 16 POS STR
CONN HEADER BRKWAY 0.100 30 POS STR
CONN HEADER 4 POS SGL PCB 30 GOLD
CONN FMALE ON BRD 10 POS VERT T/H
CONN JACK BANANA UNINS PANEL MOU
CONN JACK BANANA UNINS PANEL MOU
INDUCTOR PWR 2.42 µH SMD
INDUCTOR POWER 1.0 µH 9.2 A SMD
MOSFET N-CH 100 V 35 A
MOSFET N-CH 100 V 35 A
MOSFET N-CH 100 V 35 A
MOSFET N-CH 100 V 35 A
TRANSISTOR NPN 45 V 100 MA SMD
MOSFET P-CH 60 V 8 A
MOSFET N-CH 40 V 100 A
MOSFET N-CH 40 V 100 A
MOSFET N-CH 40 V 100 A
MOSFET N-CH 40 V 100 A
RES 2.00 Ω 1/8 W 1% SMD
RES 24.9 kΩ 1/3 W 1% SMD
Rev. B | Page 40 of 43
ADP1055-EVALZ User Guide
Manufacturer Part Number
Kemet C1210C475K5RACTU
Murata C1608X7R1E105K
TDK C3216X7R1E106K160AB
AVX 08055C102KAT2A
Kemet C1812C333J1GACTU
Keystone 5019
Digi-Key CMD15-21SRC/TR8
Central Semiconductor CMPD5001-TR
Visual CMD15-21VRC/TR8
Central Semiconductor CMPD5001-TR
Visual CMD15-21VRC/TR8
Diodes 1N5819HW-7-F
Diodes 1N5819HW-7-F
Diodes MMBD7000HS-7-F
Diodes MMBD7000HS-7-F
Keystone 5019
Keystone 5019
Keystone 5019
Keystone 5019
Keystone 5019
Emerson 108-0740-001
Emerson 108-0740-001
Emerson 131-3701-261
TE 4-102973-0-08
TE 4-102973-0-15
FCI 69167-104HLF
TE Conn 8-215079-0
Emerson 108-0740-001
Emerson 108-0740-001
Pulse PA1494.242NL
Vishay Dale IHLP2020CZER1R0M01
International IRFR540ZPBF
International IRFR540ZPBF
International IRFR540ZPBF
International IRFR540ZPBF
NXP BC847C,215
Vishay SI7463DP
Infineon BSC017N04NS G
Infineon BSC017N04NS G
Infineon BSC017N04NS G
Infineon BSC017N04NS G
Yageo RC0805FR-072RL
Digi-Key CRCW121024K9FKEA
