PART LIST—Model No. PFIVEX92314.0
Item Description
1 Meter
2 Meter wire 1
4 Round end cap Φ25*16
5 Handle bar
9 Arc washer d8
10 Hex screw M8*30
12 End cap Φ12*11*Φ3
13 Hex screw M5*12
14 Handle bar post
15 bushing F38*38*120
16 End cap F30*30*16
17 Elliptical bush PT70*30*66
18 Saddle tube post
19 Saddle across tube
20 Saddle
21 Elliptical end cap PT60*20*30
22 Big knob M16*1.5*27*Φ56
23 Elliptical bush PT70*30*145
24 Brake handspike Φ8*189
25 Brake spacer bush 1 Φ12*Φ9*15
26 Meter bracket
27 Brake fixed bracket
28 Nut M8*5
29 Spring Φ1.5*Φ24*21*N6
30 Fixed block for brake 13*13*11.5
31 Press block Φ27*1.5*Φ24*16
32 End cap Φ35*3*M30*1.5*8*M16*1.5
33 L shape knob M16*1.5*18
34 String roller Φ8
35 Hex nut M6
36 Nylon nut M6
37 Screw M5*30
38 washer d5*Φ10*1
39 Nylon nut M5
40 Brake spring broad
41 washer d6*Φ12*1.2
42 Hex knob M6*12
43 Brake broad
44 spring Φ2*Φ24*Φ13*15*N5
45 Brake block 110*27*30
46 Wool felt 110*30*6
47 Screw ST4.8*12
Note: Specifications are subject to change without notice. For information about ordering replacement
parts, see the back cover of this manual. *These parts are not illustrated.
Qty. Item Description
1 48 Induction block
1 49 Screw ST4*12
2 50 Wheel cover
1 51 Fly wheel
2 52 Spacer Φ18*Φ12.2*6
2 53 Nut M12*1*H19.5*S19
1 54 Hex nut M12*1*H6*S19
3 55 Rotation induction
1 56 Screw M6*60*Φ12*5
1 57 Hex nut M6
2 58 Bearing 6001-2RS
2 59 Two ways Chain wheel(16 gear )
1 60 Nut M33*1*Φ41*4 left
1 61 Axe for flywheel
1 Φ12*150*M12*1*50*31
1 62 Spacer Φ18*Φ12.2*3
2 63 Pedal YH-76X
1 64 End cap for crank Φ25*7
1 65 Hex nut M10*1.25
1 66 Crank
1 67 Plastic roller d17
1 68 Shaft bush
1 69 Bearing 6203-2RS
1 70 Inner chain cover
1 71 Washer d5*Φ10*1
1 72 Screw ST4.8*16
1 73 Spacer Φ22*Φ18*5
1 74 Shaft Φ17*175*57*74.2*S25
1 75 Chain 1/2"*1/8"*104
1 76 Chain cover
1 77 Main frame
2 78 Washer d6*Φ16*1.2
4 79 Screw M6*12
2 80 Rear end cap PT80*40
1 81 Washer d8*Φ16*1.5
2 82 Hex screw M8*45
2 83 Front bottom tube
1 84 Back bottom tube
1 85 Screw 4.2*16
1 86 Adjustable end cap PT80*40
1 87 Inner hex spanner S6
1 88 spanner S13-14-15
15
Qty.
1
11
2
1
2
2
3
1
2
4
2
1
2
1
2
2
2
2
2
1
1
2
1
11
2
1
1
1
1
1
2
2
2
4
4
1
1
4
2
1
1
