3. Slide the three Support Spacers (21) and two
Middle Backrest Supports (10) onto the Backrest
Frame (7) as shown. Make sure that the round
holes in the Support Spacers are toward the
back.
4. Attach the Top Backrest Support (9) and the
Handle (8) to the Backrest Frame (7) with two M6
x 27mm Flat Head Screws (24), the Upper
Bracket (36), and two M6 Nylon Locknuts (32).
Remove the paper backing from the Backrest
Pad (22) and press the Backrest Pad onto the
Top Backrest Support (9). Note: The exercise
bench can be used after 15 minutes. Use the
exercise bench carefully for the first 24 hours
while the Pad adhesive sets completely.
3
4
24
22
24
6
21
10
21
10
21
Back
7
8
9 36
32
7
