Wireless Remote Control - eTIGER S3b Sim Secual Manual

Wireless Remote Control

Disarm
LED indicator
Arm
Arm the system
Press the Arm button " " to arm the alarm
system. The LED indicator lights up (the
control panel beeps once). The system is
armed.
If an intruder is detected, the siren rings
out. (The siren turns off after 3 minutes as
per default settings.) In the meantime, the
system dials the pre-stored phone numbers
automatically.
Disarm the system
Press the Disarm button " " to disarm the
alarm system. The LED indicator turns off
(the control panel beeps twice). The system
is disarmed.
Home Mode
Press the Home Mode button " " on the
remote control. The system state LED is on. All
the sensors in regular zones are armed except
those in the Home Mode zone. The sensors
in the Home Mode zone are disarmed so that
users can move inside their home.
20
SOS
Home Mode
Mute Mode
Press the Home Mode button " " and the
Arm " " or Disarm " " button immediately
after. Doing so, the control panel does not
ring out when you arm or disarm your
system.
Emergency Mode
Regardless the status of the system, the alarm
is triggered when the SOS button "SOS" is
pressed on the remote control.
At the same time, the control panel sends a
notification by SMS ("RC-01 SOS", 01 being
the remote control's number) and dials the
pre-stored phone numbers.
Register in the control panel
Type your password followed by the Connection button " " on the control panel to enter the
Connection Mode. Press any button on the remote control.
Specifications
Power supply:
DC 3V (CR2025 button battery x1)
Static current:
10 uA
Operating current:
≤7 mA
Transmission distance
≤ 80 m (in open area)
Radio-frequency:
433MHz (±75KHz)
Housing material:
ABS plastic
Operating conditions:
Temperature: -10°C ~ +55°C
Relative Humidity: ≤80%
(non-condensing)
Dimensions:
57 x 31 x 11 mm
21
