Media Supply Positions
Therearefoursetsofslotsandthreadedholesintheprinter' scentersec-
tionforthemediasupplyrollpostorrotatinghub(optional).Theseslots
allowthelargestpossiblerollsizeto
t,giventhelimitationsofanyliner
takeupunitand/orthefullenclosureprovidedbythelongsidedooror
Megatop.Thepositionsareindicatedbynumbersengravedinthecenter
section.
·Position1isusedwhenthemediacompartmentisfullyenclosedbya
longsidedoor,regardlessoftheexistenceofanyintegrallinertakeup
unit.Maximumrollsizeis152mm(6inches).
·Position2isnotused.
·Position3isusedwhentheprinterhasanintegrallinertakeupunit
andalongsidedoor.Thispositionisalsousedwiththe8-inch
Megatop.Maximumrollsizeis213mm(8.38inches).
·Position4isnotused.
Theprintercanalsouseanexternalmediasupplylocatedbehindthe
printer,exceptwhenithasan8-inchMegatop.
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Chapter 2—Installation
Position 3
Position 2
(not used)
Position 1
Position 4
(not used)
