Label Stop Sensor
Thelabelstop/blackmarksensor(LSS)isaphotoelectricsensorthat
controlstheprinter'smediafeedbydetectinggapsbetweenlabels,orslots
orblackmarksincontinuousstock,dependingontheprinter'ssetup
inregardofmediatype(seeChapter6,"SettingUpthePrinter").An
obviousprerequisiteisthattheLSSmustbealignedwiththegaps,slots,
orblackmarks.Ifusing-irregularlyshapedlabels,aligntheLSSwiththe
fronttipsofthelabels.
TheLSScanbemovedlaterallybetween5fixedpositions.Thereisone
partofthesensorontopoftheuppermediaguideandanotherpart
underneaththelowerguide.Thesemustbeadjustedindividuallytothe
sameposition.Usingasmallscrewdriver,pushtheminwardsasfaras
theygoandthenpullthemout—oneatthetime—whilecountingthe
clicksfromthesnap-locks.Aholeinthebottomplatefacilitatesadjust-
mentofthelowersensorpackage.
Thevariousdetectionpointsofthesensorinrelationtotheinneredgeof
themediaareasfollows:
Oneclickout
Twoclicksout
Threeclicksout
Fourclicksout
Fiveclicksout
One diode +
One sensor
One diode +
One sensor
Intermec EasyCoder PF4i Compact Industrial—User 's Guide (Fingerprint)
Lower part of LSS
Chapter 12—Adjustments
Upper part of LSS
