Optional Interfaces
Theprintercanoptionallybefittedwithoneofthefollowinginterface
boardsattheright-handsideoftheprinter'srearplate:
·DoubleSerialInterfaceBoard(device"uart2:"and"uart3:")
·Serial/IndustrialInterfaceBoard(device"uart2:")
·IEEE1284ParallelInterfaceBoard(device"centronics:")
Regardlessofanyoftheinterfaceboardmentionedaboveisinstalled,the
printercanalsobefittedwithoneofthefollowingEasyLANinterface
boardsforconnectiontoaLocalAreaNetwork(LAN):
·EasyLANEthernetInterface(device"net1:")
·EasyLANWirelessInterface(device"net1:")
Double Serial Interface Board
Serial/Industrial Interface Board
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Appendix C—Interfaces
"uart3:"
RS-232,
RS-422 non isolated,
or 20 mA current loop
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
Industrial interface
8 digital In ports
8 digital Out ports
4 relay ports
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
