User Guide

3. Display and menus

3.1 Home Screen

When pressing
of eco:
Time is shown with the dashed circle, each segment representing
30 minutes.
• Black segments = periods with comfort temperature.
• White segments = periods with setback temperature.
• Flashing segment = current time.
The chosen programme P 0 , P 1 , P 2,
or (Pause)
Day of week
The set temperature*
* eco is displaying the set temperature, not the measured room temperature.

3.2 Programme menu

1.
Display symbols in the Programme menu
Programme without automatic temperature reduction. This programme maintains the
P 0
comfort temperature of 21 degrees constant all day and night.
Saving programme which as default lowers the temperature to 17 °C at night (22:30 -
P 1
06:00 hrs). Time and temperature are configurable.
Extended saving programme which as default lowers the temperature to 17 °C at
P 2
night (22:30 - 06:00 hrs), and during the day on weekdays (08:00 - 16:00 hrs). Time and
temperature are configurable.
Pause program. The thermostat will maintain a constant temperature of 4-10 °C in the
room, ensuring frost protection.
Note! Symbols must be flashing to be activated.
12 06/2015
the Home Screen appears with basic information on programming and operation
eco Intelligent Radiator Thermostat
(Travel)
To select the Programme menu:
If the display is off, press
to open the programme menu.
Use to shift between the programmes, press
to confirm. The chosen programme is flashing.
VIJPD102
, then press again
