EVAL-ADV7625-SMZ User Guide
TxA
TxB
RxE
RxD
Table 1. Evaluation Board Hardware Components
Reference
Designator Function
J12 Power connector
SW1 ADSP-BF524
P1 ADSP-BF524
RS-232 port
J1 ADSP-BF524
SW6 SHARC® reset
J11 SHARC JTAG
J2, J3, J4, J5, J6 HDMI inputs
J7, J8 HDMI outputs
J10 Digital audio
interface
RxC RxB RxA
Figure 3. Photograph of Board with Most Frequently Used Connectors Labeled
Description
J12 is where the 5 V, 3.6 A power supply is connected.
reset This switch resets the
RS-232 interface between the
JTAG The ICE-100B or the
source code debugging.
This switch resets the SHARC processor.
The ICE-100B or the
code debugging.
J2 is RxA, J3 is RxB, J4 is RxC, J5 is RxD, and J6 is RxE.
J7 is TxA, and J8 is TxB.
A modified SHARC Audio EZ-Extender® board can be connected to this if analog audio output is
desired.
ADSP-BF524 processor.
ADSP-BF524 and the computer (for user control and debug output).
HPUSB-ICE is connected here to program the
HPUSB-ICE is connected here to program the SHARC flash or to execute source
Rev. 0 | Page 5 of 12
UG-603
ADSP-BF524
RS-232
ADSP-BF524
JTAG
ADSP-BF524 flash or to execute
