- Page 1 ATR 700TVL COLOR DOME CAMERA CMD2182/2186 Series D/N ATR 700TVL VARI-FOCAL DOME CAMERA CMD02182X/2186X Series INSTRUCTION MANUAL...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... - Page 3 CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
- Page 4 CONGRATULATIONS Thank you for purchasing this ATR 700TVL Color Dome Camera. You now own one of the many fine CCTV products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition. With reasonable care, it will provide years of reliable performance.
-
Page 5: Warranty Information
WARRANTY INFORMATION Please complete the following product purchase information. The factory will requests this information when contacted for technical support, or warranty repair. It is also valuable in case of loss or theft. Purchase Date Serial Number Model Number... -
Page 6: Part Description & Dimension
PART DESCRIPTION & DIMENSION Unit : mm VIDEO OUTPUT JACK DC POWER INPUT (DC12V 10%) JACK DC12V (NON-POLARITY INPUT) OR AC24V POWER INPUT BASE FIX RING INSIDE COVER DOME COVER LENS... - Page 7 BRACKET OSD SETTING TILT AZIMUTH (CMD2182/2186) RIGHT LEFT DOWN OSD SETTING TILT BRACKET AZIMUTH ZOOM ADJUSTMENT FOCUS ADJUSTMENT (CMD2182X/2186X) OSD SETTING (UP): Push up to move the cursor upwards or to select items. (LEFT): Push left to move the cursor to the left and to select or adjust the parameters of the selected item.
-
Page 8: Configuration Of The Menu
CONFIGURATION OF THE MENU SETUP LENS AUTO TYPE DC MENU MANUAL MODE AUTO OPEN CLOSE SPEED(000~255) SHUTTER/ AUTO HIGH LUMINANCE MODE AUTO IRIS SHUT+AUTO IRIS BRIGHTNESS(000~255) LOW LUMINANCE MODE AGC OFF BRIGHTNESS x0.25 x0.50 x0.75 x1.00 MANUAL MODE SHUT+AGC SHUTTER 1/60(1/50) 1/100(1/120) 1/250~1/10000 AGC 6.00 12.00 18.00 24.00 30.00 36.00 42.00 44.80 WHITE BAL SPEED(000~255) - Page 9 PRIVACY AREA SEL 1/8~8/8 [000~244(NTSC), 000~288(PAL)] BOTTOM [000~244(NTSC), 000~288(PAL)] LEFT [000~474(NTSC), 000~468(PAL)] RIGHT [000~474(NTSC), 000~468(PAL)] COLOR(1~8) TRANSP 0.00 0.50 0.75 1.00 MOSAIC OFF ON NR MODE Y/C OFF/ Y/ C Y LEVEL(000~015) C LEVEL(000~015) CAMERA ID SYNC INT LANGUAGE ENGLISH DEUTSCH FRANCAIS PYCCK PORTUGUES ESPANOL...
-
Page 10: Setting Menu And Function
1. Without LENS option in the CMR2182/2186N/P . 2. Only DC mode on the TYPE option. Because a DC auto iris lens is used with the CMD2182/2186X3.6N/P. 3. Please select AUTO mode on the SHUTTER/AGC option. If you select MANUAL... -
Page 11: Specifications
SPECIFICATIONS ATR 700TVL COLOR DOME CAMERA CMD2182N/P3.6 CMD2182N/P6 CMD2186N/P3.6 CMD2186N/P6 Model No. Focal Length 3.6mm 6.0mm 3.6mm 6.0mm Iris F2.0 F1.8 F2.0 F1.8 Lens 44.5 44.5 Angle of View 54.5 33.1 54.5 33.1 DC12V 10% Power Input Voltage DC12V 10% AC24V 10% System NTSC or PAL... - Page 12 D/N ATR 700TVL VARI-FOCAL DOME CAMERA Model No. CMD2182X3.6N/P CMD2186X3.6N/P Focal Length 3.3~12mm Iris F1.4 Lens 89.8 ~ 23.9 Angle of View 63.6 ~ 17.9 125.7 ~ 29.9 DC12V 10% Power Input Voltage DC12V 10% AC24V 10% System NTSC or PAL Pick Up Element 1/3"...
- Page 13 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-CMD218CSE...
