EVAL-AD7124-4SDZ User Guide

BILL OF MATERIALS

Table 4.
Reference
Designator Description
A0, A1, A5, A6, J2 Straight PCB mount SMB jack, keep hole clear of
solder
A2 Miniature thermocouple connector
C1, C17, C29, C30, C43, Capacitor, ceramic, 6.3 V, X5R, 0603, 4.7 µF,
C47 ±10%
C2, C22, C25, C26, C36, Capacitor, ceramic, 50 V, X7R, 0603, 0.1 µF, ±10%
C38, C54, C55
C3, C45, C46 Capacitor, ceramic, 10 V, X5R, 0603, 4.7 µF, ±10%
C4, C6 Capacitor, 0805, 1 µF, 50V, X7R, 1 µF, ±10%
C5, C7, C8, C9, C16 Ceramic capacitor, not inserted, 0402
C10 to C12, C24, C27, Ceramic capacitor, 50 V, NPO, 0603, 0.01 µF
C28
C13, C14, C18, C20, Capacitor, ceramic, 16 V, X7R, 0402, 0.1 µF, ±10%
C21, C31, C33, C34,
C44, C50 to C53
C15, C37 Capacitor, 6.3 V, 1 µF, ±10%
C19, C59 Ceramic capacitor, 25 V, NPO, 0603, 0.01 µF
C23 Ceramic capacitor, 50 V, NPO, 0603, 0.1 µF
C32, C35, C39, C48, Capacitor, ceramic, 50 V, X5R, 1210, 10 µF
C49
D2, D6 Red LED, high intensity (>90 mCd), 0603
D4 LED, SMD, green
D5 Diode, Zener, 0.5 W, 5.1 V, BZT52
GND, GN1 to GND6, Test point, not inserted, keep hole clear of solder
MCLK, REF+, REF−,
REFOUT, S1 to S8, S1' to
S8', TDIN, TDIN1,
TDOUT, TDOUT1,
TSCLK, TSCLK1, TSYNC,
TSYNC1, T\CS, T\CS1
J1 120-way connector, 0.6 mm pitch
J3 Socket terminal block, 3.81 mm pitch
J4 Screw terminal block, pitch 3.81 mm
J5 DC power connectors, 2 mm, SMT, power jack
J6, J11 8-pin terminal header, pitch 3.81 mm, vertical
J7 Connector, pitch 3.81 mm, right angle, 1 × 4-pin
J8, J10 8-pin terminal header, pitch 3.81 mm, vertical
J9 Screw terminal block, pitch 3.81 mm, 1 × 4-pin
J12 PCB pads, 6-way solder slot for Analog Devices
PCB, 6-way
J13 7-way SSW, 2.54 mm vertical socket
J14 7-way sip, 2.54 mm, TH header
J15 Do not insert
L3 Ferrite bead, 0.3 Ω at dc, 1000 Ω at 100 MHz,
350 mA, 0805, 1000 Ω
LK1, LK2 3-pin (3×1), 0.1" header and shorting block in
Position A
1
Manufacturer
Tyco
Omega
Murata
Murata
Kemet
Murata
N/A
Phycomp
Murata
Murata
N/A
N/A
Murata
Avago Tech
OSRAM
Vishay
N/A
Hirose
Phoenix
Contact
Phoenix
Contact
Kycon
Phoenix
Contact
Phoenix
Contact
Phoenix
Contact
Phoenix
Contact
Aragorn
Samtec
Samtec
N/A
Tyco
Harwin
Rev. 0 | Page 27 of 29
1
Part No. Stock Code
1-1337482-0 Do not insert
PCC-SMP-U-50 Do not insert
GRM188R60J475K FEC 173-5527
GRM188R71H104K FEC 882-0023
C0603C475K8PACTU FEC 157-2625
GRM21BR71H105KA12L FEC 173-5541
N/A Do not insert
2238 586 15636 FEC 722-236
GRM155R71C104K FEC 881-9742
GRM188R70J105KA01D FEC 184-5765
N/A Do not insert
N/A Do not insert
GRM32ER61H106K FEC 184-5764
HSMC-C191 FEC 855-8528
LGQ971 Digikey 475-1409-1-ND
BZT52B5V1-V-GS08 FEC 161-7767
N/A Do not insert
FX8-120S-SV(21) FEC 132-4660
MC 1.5/3-G-3.81 FEC 370-4737
1727023 Do not insert
KLDX-SMT2-0202-A MOUSER 806-KLDX-
SMT20202A
MC 1,5/ 8-G-3,81 FEC 370-4774
MC 1,5/ 4-G-3,81 and Do not insert
180-3594
1727078 Do not insert
1727036 FEC 370-4592
ADT7320-CJC-PCB ADT7320-CJC-PCB
SSW-107-01-T-S FEC 180-3478
TLW-107-05-G-S FEC 166-8499
N/A Do not insert
BMB2A1000LN2 FEC 119-3421
M20-9990346 and FEC 102-2249 and
M7566-05 150-411
UG-855
