UG-855
Reference
Description
Designator
LK3, LK5 2-pin (0.1" pitch) header and shorting shunt
LK4, LK6 4-pin (2×2) 0.1" header and shorting block
Q1 MOSFET transistor
Q2 Transistor, NPN, SOT-23
R1 Resistor, not inserted, 0603
R2 to R4, R7, R48 SMD resistor, 100 kΩ, 1%
R5, R6, R8, R71 Resistor, 1%, 0402, 10 kΩ
R9 to R13, R19 to R22, Resistor, 0402, 0 Ω, 1%
R35 to R38, R58, R59,
R61, R62, R70
R14 Resistor, 0402, 1%, 30 kΩ
R15, R17, R18, R24 SMD resistor, 10.2 kΩ, 1%
R16 Resistor, 0402, 1%, 69.8 kΩ
R23 Resistor, 0402, 1%, 86.6 kΩ
R25, R57 Resistor, 0402, 1%, 15 kΩ
R26, R27, R29, R30, Resistor, 0603, 1 kΩ, 1%
R32, R40
R28 Thermistor, 1950 Ω to 1990 Ω
R31, R90 Resistor, not inserted, 0402
R33, R34, R39, R47, Resistor, 0603, 0 Ω, 1%
R81 to R84, R87, R89
R42 to R45 Resistor, thick film, 10 kΩ, 62.5 mW, 5%
R49 to R52 Resistor, 1206, 0 Ω, 5%
R53 Resistor, 0402, 27 kΩ, 1%
R54 Resistor, thick film, 4.53 kΩ, 63 mW, 1%
R55 Resistor, 0402, 1%, 61.9 Ω
R56 Resistor, 0402, 57.6 kΩ, 1%
R60 Resistor, thick film, 2.4 kΩ, 0603, 100 mW, 1%
R88 Resistor, 0603, not inserted
SL2, SL3, SL7 2-way solder link (use 0 Ω, 0603 resistor)
SL5 2-way solder link (use 0 Ω, 0603 resistor)
STAR3 Ground link
U1 32k I
U2 Linear regulator 5 V, 20 V, 500 mA, ultralow
noise, CMOS
U3 Quad voltage monitor and sequencer
U4 50 mA, high voltage, micropower linear
regulator, ADJ
U5 4-channel, low power, low noise, Σ-Δ ADC
U6 2.5 V low noise reference
U7, U10 50 mA, high voltage, micropower linear
regulator, 3.3 V
V1 to V4 1206, place holder
N/A means not applicable.
1
2 C serial EEPROM
EVAL-AD7124-4SDZ User Guide
Manufacturer 1
Harwin
Harwin
Vishay Siliconix
ON Semi-
conductor
N/A
Multicomp
Phycomp
Vishay
Multicomp
Multicomp
Multicomp
Multicomp
Multicomp
Multicomp
Infineon
N/A
Vishay Draloric
Yageo
Multicomp
Multicomp
Vishay Dale
Multicomp
Multicomp
Yageo
N/A
N/A
N/A
N/A
Microchip
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
Analog Devices
N/A
Rev. 0 | Page 28 of 29
Part No. 1 Stock Code
M20-9990246 FEC 102-2247 and
150-411
M20-9983646 and FEC 1022244 and
M7566-05 150-411 (36-pin strip)
SI2304DDS-T1-GE3 FEC 185-8939
MMBT3904LT1G FEC 145-9100
N/A Do not insert
MC 0.063W 0603 1% 100K FEC 933-0402
CRCW040210K0FKEAHP FEC 173-8864
CRCW04020000Z0ED FEC 146-9661
MC 0.0625W 0402 1% 30K FEC 135-8082
MC 0.0625W 0402 1% 10K2 FEC 180-3137
MC 0.0625W 0402 1% 69K8 FEC 180-3735
MC 0.0625W 0402 1% 86K6 FEC 180-3744
MC 0.0625W 0402 1% 15k FEC 1358073
MC 0.063W 0603 1% 1K FEC 933-0380
Q62705-K110 Philips (Arrow)
KTY81/110
N/A Do not insert
CRCW06030000Z0EA FEC 146-9739
RC0402JR-1310KL FEC 179-9316
MC 0.125W 1206 0R FEC 933-6974
MC 0.0625W 0402 1% 27K FEC 135-8081
CRCW04024K53FKED FEC 115-1244
MC 0.0625W 0402 1% 61R9 FEC 180-2915
MC 0.0625W 0402 1% 57K6 FEC 185-1295
RC0603FR-072K4L FEC 179-9329
N/A Do not insert
Insert in Link Position A FEC 933-1662
Insert in Link Position B FEC 933-1662
N/A N/A
24LC32A-I/MS FEC133-1330
ADP7104ARDZ-5.0 ADP7104ARDZ-5.0
ADM1185ARMZ-1 ADM1185ARMZ-1
ADP1720ARMZ-R7 ADP1720ARMZ-R7
AD7124-4BCPZ AD7124-4BCPZ
ADR4525BRZ ADR4525BRZ
ADP1720ARMZ-3.3-R7 ADP1720ARMZ-3.3-R7
N/A Do not insert
