ANAN Hardware Requirements

13.8vdc minimum, 25A [Recommended
Note: some switching DC supplies create objectionable EMI/RFI which may degrade performance of the
ANAN transceiver.
Ham band resonant 50 ohm HF antenna for normal Ham Radio operation.
Suitable Dummy Load required for calibration.
PC condenser microphone terminated in 3.5mm - 1/8" plug, for SSB "phone" operation.
CW key terminated in 3.5mm - 1/8" Stereo plug, for CW operation.
A set of stereo speakers or stereo headphones with a 3.5mm - 1/8" stereo plug.
Note: If a mono plug or a shorted stereo plug is wired into the rear panel AUX/IO connector, damage
will occur to the audio output IC. Do NOT short these stereo pins or connect either side to ground!

ANAN Recommended Software requirements

Windows XP or later – Win7 [or newer] recommended.
Microsoft .NET 4.0 Framework or later required.
OpenHPSDR PowerSDR
Windows XP or Windows 7
Linux
MacOS X
Android
Java [for many platforms)
OpenHPSDR Software and download information http://openhpsdr.org/download.php.
Copyright Apache Labs © ANAN-200D
:
PowerSDR™, KISS Konsole, ghpsdr3
cudaSDR, cuSDR, ghpsdr3
Heterodyn
"OpenHPSDR" by John Melton GØORX/N6LYT
"openhpsdrJ" by John Melton GØORX/N6LYT
11 June 22, 2015
