Chapter 5 – How to operate CW

Sample Rate

Select a SAMPLE RATE best suited to your CW tuning style from the Settings → AUDIO menu
Note: the appearance of the Panadapter can be adjusted with the ZOOM settings, Sample Rate, and
SETUP –-> DISPLAY –-> RX1 [or RX2] –-> Fast Fourier Transform Size [min to max] Bin width.

Iambic A/B

Select Iambic A or B from the Settings → DSP → CW menu
Note: Unselecting Iambic allows you to use the Paddle input in "Bug" mode or with a Straight Key connected to
the DAH paddle input.
