Click on the desktop ICON to start OpenHPSDR/PowerSDR-mRX.
If a OpenHPSDR/PowerSDR_mRX icon is not clearly apparent on your screen, use your start menu to locate the
program.
The program will begin with the "WISDOM" optimization. A one time DOS FFT optimization screen will
appear. Wait for this process to finish and the DOS screen will disappear.
Wait for the message that it is OK. select "OK" to finish. This may take several minutes on a slow
computer.
Connect your Transceiver to your Power Supply using the supplied fuses.
Turn on your power supply. Push the POWER ON button on the ANAN Transceiver.
The IDLE receiver current of the ANAN-200D is approximately 800ma [1.8A)
Open the PowerSDR application, then press the POWER button on OpenHPSDR/PowerSDR™.
Wait a few seconds for Network Discovery and then click on the Setup Menu selection.
Click on the "Setup" menu selection to configure the OpenHPSDR/PowerSDR software.
OpenHPSDR/PowerSDR basic display screen
