Here is what you need to get started with the ANAN-100/D

ANAN-100/D Hardware Requirements

1. 13.8vdc minimum, 25A

Note: some switching DC supplies create objectionable EMI/RFI which may degrade
performance of the ANAN-100/D transceiver.
2. Ham band resonant 50 ohm HF antenna and Dummy Load required for calibration.
3. PC microphone terminated in 3.5mm - 1/8" plug, optional.
4. CW key or keyer terminated in 3.5mm - 1/8" Stereo plug, optional.
5. A set of stereo speakers or stereo headphones with a 3.5mm - 1/8" stereo plug should be
connected to the front panel headphone jack. The rear panel speaker jack should NOT be used for
speaker or headphone connections! The rear panel speaker jack provides a balanced, Left channel
speaker output only and will not work as expected with stereo speakers. The rear panel audio was
designed for someone working in the field where they might have a simple portable 2-wire speaker.
WARNING: If a mono plug or a shorted stereo plug is inserted into the rear panel Speaker jack,
damage will occur to the audio output IC. Do NOT short these stereo pins or connect either side to
ground!
6. DO NOT TURN THE ANAN-100/D RADIO ON until P*SDR software is properly installed
and configured.

ANAN-100/D Recommended Software requirements

1. Windows XP or later – Win7 recommended.
2. Microsoft .NET 4.0 Framework or later.
3. OpenHPSDR/P*SDR mRx 3.0.XX or OpenHPSDR/P*SDR 2.2.XX 2Rx version
** please see OpenHPSDR Software and download information http://openhpsdr.org/download.php.
