Antenna Control menu allows you to control the following options:

Software SWR Protection will reduce power output when high SWR levels are detected.
Disable on Tune Pwr < 10W will disable Software SWR protection when the Tune power level is less
than 10 watts. The Tune power level can be set on the Setup, Transmit tab.
ATT on TX. This option inserts attenuation in the receiver when the ANAN-* is transmitting. This can
prevent or reduce the ADC/Receiver overload warnings during transmit.
RX 1 Out on Tx. This option switches the receive path from ANT[n] to the rear panel Bypass connector.
Disable ANAN PA [only functional via the XVTR form].ANAN-200D users may wish to manually calibrate
the Transmitter Power Output settings within OpenHPSDR/PowerSDR™
OpenHPSDR/PowerSDR/OpenHPSDR allow small adjustments of transmitter power output.
