Chapter 4 – How to operate Digital modes

Clarification CCS [30W]/ICAS [100W] operation

AM/FM, CCS [Continuous Commercial Service] 30W
SSB, CW and all ICAS modes [Intermittent Commercial/Amateur Service] 100W PEP
The Power Amplifier MOSFET transistors have characteristics that far exceed the needs of normal Transceiver
operation. They are quite rugged. However, other internal components such as the Filters, Integrated Circuits,
and some small SMT parts must also be considered when modes with high duty cycles are in use. There are
three voltage rails all of which have thermal shutdown protection built in.
Digital modes such as PSK31, RTTY [AFSK), WSPR, JT65A work very well with PowerSDR control software and
Apache Transceivers.
Digital operation of a Software Defined Radio may require additional Utilities and supporting software in order to
complete the complex software [virtual) interconnections for digital operation. Fldigi will be used as an example.
There are dozens of high quality, digital programs available:
Helpful catalog of Ham Radio digital software:
Dxzone Software Catalog
W1HKJ Fldigi
VSP, Com0Com, RigCAT, Omni-Rig, VAC, VB-Audio
W1HKJ Fldigi http://www.w1hkj.com/FldigiHelp-3.21/html/index.html
Virtual Audio Cable or VB-AUDIO connections can easily be accomplished with the $25-$40
program called "VAC" or the VB-AUDIO virtual audio cable
VAC is available here
VB-Audio is available here:
VB-Audio Mixer here:
You may also need virtual Serial Ports to interface software PTT connections. Here are two popular
Utilities:
http://k5fr.com/ddutilwiki/index.php?title=VSP_Manager
http://sourceforge.net/projects/com0com/
The Apache Yahoo Group has several helpful digi operating documents:
https://groups.yahoo.com/neo/groups/apache-labs/ files
SignalLink-Hermes-WiringDiagram.pdf
https://xa.yimg.com/df/apache-labs/PowerSDR-Fldigi_Guide_V2.0.pdf
The KC9XG Yahoo Group also has many helpful diagrams and documents:
https://groups.yahoo.com/neo/groups/KC9XG-SDR/files
Various libraries such as ComCat, RigCat and Omni-Rig may be necessary for CAT [PTT and VFO)
control:
http://www.dxzone.com/tag-rig-cat-control/
http://www.w1hkj.com/download.html
Copyright Apache Labs © ANAN-200D
http://www.dxzone.com/catalog/Software/
http://software.muzychenko.net/eng/vac.htm#download
http://vb-audio.pagesperso-orange.fr/Cable/
http://vb-audio.pagesperso-orange.fr/Voicemeeter/index.htm
29 June 22, 2015
