Original 2013 Users Guide

Please refer to the Technical Reference document [formerly User Guide v3.4] for information about various
microphones and how to adapt them to the Apache Transceiver. You may find this reference helpful:
:
http://www.apache-labs.com
Website

Balanced Audio Input is not implemented in the current Apache Labs Transceivers.

The LEFT LINE level input is currently selectable in PowerSDR as an alternative to the mic input.
Balanced audio is not supported by the Audio ADC hardware used in the ANAN radios. If a balanced input is
required then an external balanced to unbalanced transformer [or active electronic equivalent] will be required.

Multiple independent .xml databases

Thank you Doug W5WC for this important information
Go to the Properties of the shortcut.
At the end of the Target you can add the new directory path using the
command line argument –datapath:<"directory path">
To create a new directory for the ANAN-200D radio I use the name PowerSDR
ANAN_10 like this:
start -datapath:"%appdata%\FlexRadio Systems\PowerSDR ANAN_10\"
My new Target will look like this:
"C:\Program Files [x86]\OpenHPSDR\PowerSDR RX2 [W5WC]\PowerSDR.exe"
-datapath:"%appdata%\FlexRadio Systems\PowerSDR mRX\"
When you start PowerSDR using the modified shortcut you will receive
this message the first time.
Ensure the directory path is correct. The click on Yes.
You will then get the normal startup with a new wisdom file and database
created in the new folder.
