Apache Labs ANAN-200D User Manual page 55

13
14
15
16
17
18
19
20
21
22
23
24
25
Copyright Apache Labs © ANAN-200D
PTT input, connected to 3.3V via 1K
pullup resistor
OCREF Open-Collector
reference/flyback diodes
OC5 User open-collector output 6
OC3 User open-collector output 4
OC1 User open-collector output 2
User Digital input 2: Connected to
3.3V via 1K pullup
Right channel speaker, pair with pin 6
User Analog input 2: 0-3V max
Analog Ground
Right channel line Out
Left channel phones output
not implemented
Analog Ground
55
resistor
not implemented
1
24
22
20
18
16
14
12
10
8
6
2
June 22, 2015
