Polycom realpresence group series Setup Sheet page 9

Polycom RealPresence
®
Base
Legs (4)
M10 x 50 flanged head cap screw (8)
Glides (4)
Flat washer (4)
Lock washer (4)
Optional: Casters (4)
Flat washer (4)
Lock washer (4)
Vertical Support (2)
M10 x 25 flanged head cap screw (6)
Lower display rail
M10 x 25 flanged head cap screw (4)
Handle (2)
Upper display rail
M10 x 25 flanged head cap screw (8)
Front door
Nylon spacer
10-32 x 1/2" pan head screw (2)
Mesh grill (2)
10-32 x 1/2" pan head screw (6)
Display (2)
T-Nut (8)
M6 x 25 Phillips flat head screw (8)
Flat washer (8)
Display mount bracket (4)
M8 x 20 button head cap screw (8)
1/4-20 x 3.5" socket head cap screw (4)
M5-10 screw (4)
For more information about the components of the RealPresence Group Series Media Center, refer to the documentation at
http://support.polycom.com/PolycomService/support/us/support/video/group_series/group_packaged_solutions.html.
The Media Center components are heavy. Polycom recommends that two people perform the installation.
Polycom ® RealPresence
Media Center Setup Sheet
Group Series Media Center with Dual 42" AIO Displays
®
® Group Series
EagleEye IV camera
M3 x 6 phillips flat head screw (4)
Camera mount bracket
1/4-20 x 5/8 socket head cap screw (4)
Flat washer (4)
Lock washer (4)
1U shelf
Clip-on rack nut fastener (4)
10-32 x 1/2" pan head screw (4)
RealPresence Group Series 500 codec
M3 x 10 screw (2)
Power strip
Shoulder screw (2)
Power brick
Rear panel
Polycom-supplied tools:
L-Key for M8 screw
L-Key for M6 screw
L-Key for M10 screw
L-Key for 1/4-20 screw
User-supplied tools:
9/16" wrench
11/16" wrench
Phillips screwdriver (medium drive)
Phillips screwdriver (small drive)
9
