Polycom realpresence group series Setup Sheet page 5

Insert a shoulder screw onto the flange on both ends of
13
the power strip. Note that the flange should be between
the shoulder and the threads of the shoulder screw.
Install the power strip to the left vertical support, using
the two shoulder screws. Install the power brick.
Note: For 84" displays, refer to the Polycom
15
RealPresence Group Series Media Center with 84"
Display Setup Sheet Supplement.
Install the display mount brackets on the display using
two M8 x 20 button head cap screws in the second
hole down on each display bracket.
Install the supplied 1/4-20 x 3.5" socket head cap
screws at the top of each display bracket. Leave the
screws adjusted up before mounting the display to
the top rail. If you have a dual display configuration,
repeat with the second display.
Polycom® RealPresence® Group Series Media Center Setup Sheet
On the back side, install a handle on both ends of the
14
bottom display rail.
With the assistance of another person, lift the display
16
and attach the display bracket hooks over the edge of
the upper display bracket on the Media Center.
If you have a dual display configuration, repeat with
the second display.
Adjust the leveler screws as needed (does not apply
for 84" display mounts).
