Control Parameter

The Control parameter allows remote control of Display, Homing, Lamp and Shutdown.
Control Setting DMX Value
Safe
Display Off
Display On
Home All
Shutdown
Pan and Tilt Home
Other Motor Home
Audio Sync
Internal Program 1
Internal Program 1
Internal Program 1
Internal Program 1
Internal Program 1
Internal Program 1
Internal Program 1

Dim Parameter

SolaWash 19 LED fixtures provide 16-bit brightness control utilizing the Dim Coarse and Dim Fine
parameter without changing the color temperature or the beam shape. The dim values range from
Off when the DMX value = 0 to fully on when the DMX value = 255.
SolaWash 19 LED User Manual
0-9 Disables all Control settings for normal operation
20-28 Turns display off
29-48 Turns display on
49-68 Remotely homes all the fixture components
Remotely shuts down the fixture. When a fixture is shut down, the LEDs
69-130 are off and power to the motors is disabled. If a fixture is in shutdown
mode, the fixture must be homed to bring it back into operation.
131-140
Homes the driver motors for specific fixture components.
141-150
151-160 Synchronizes audio playback
161-171
172-182
183-193
Selects one of the seven factory-programmed 8-step scenes to play as a
194-204
macro
205-215
216-226
227-237
Description
CHAPTER 5
DMX Programming
