CHAPTER 3
Menu System

Set Menu

The Set Parameters menu lets you configure your fixture's motion, display, and data source
settings.
To enter the Set menu:
1. Press the MODE/ESC button to enter the first level of the menu system. The display will
MODE
/ ESC
show Address and Info as the first two options in the top menu level.
*
The red star indicates the current option.
2. Using the buttons, scroll to Set.
3. Press the button to select.

Status Options

This menu lets you configure the fixture functions listed below.
No DMX Mode
This option determines the fixture state after the DMX signal is removed. The Default setting is
Hold. You can choose from the following options:
CloseShutter: Shuts LEDs off when DMX is removed
Hold: Holds the current values for all parameters
Auto Program: Reverts to Auto Program Playback
Music Ctrl: Reverts to Music Control Playback
Pan Reverse
This menu option inverts the direction of the pan motor to coordinate movements between
fixtures mounted opposite each other horizontally.The default setting is Off. On inverts the
fixture's Pan motion.
Tilt Reverse
This menu option inverts the direction of the tilt motor to coordinate movements between fixtures
on a link facing each other vertically. The default setting is Off. On inverts the fixture's Tilt
motion.
Pan Degree
The standard pan range of a SolaWash 19 LED fixture is 0–540°. This option lets you expand the
pan range to an upper limit of 630°. To expand the pan range, scroll from the default option of
540 to 630 and press the
Encoders
Encoders maintain the Pan and Tilt position of the fixture, but may need to be disabled to perform
certain test and maintenance procedures. The default setting is On. To disable encoders, select
the Off option.
26
button to select.
