High End Systems SHOWBEAM 2.5 Getting Started

Getting Started with SHOWBEAM™ 2.5
Use the following steps to set up and configure your SHOWBEAM™ fixture:

Unpack

Unpack your SHOWBEAM™ 2.5 fixture and verify that it arrived undamaged. If the fixture is
damaged, notify both the shipping agent and your sales agent immediately.

Install Attachment Plugs

Install the correct power cord cap for your location.
colored according to the following code:
• green and yellow = earth
• blue = neutral
• brown = live
Class 1 equipment - This equipment must be earthed.

Mount

To mount the fixture upright, place the fixture on a sturdy, stable non-flammable surface
that will support a weight of 66.2 kg (146 lb).
Truss mount the SHOWBEAM 2.5 fixture using it's custom mounting bracket and clamps and a
safety cable attached to the fixture's base.
WARNING!
SHOWBEAM 2.5 projects a powerful light beam that generates intense heat.
Do not point directly at other lights on the rig.
Do not project onto flammable surfaces less than 6 m. (19.7 ft.)
Caution!
SHOWBEAM 2.5 fixtures should be installed and operated by trained personnel
only.
The cores in the mains lead are
