CHAPTER 1
Product Overview

Fixture Components

2 3 4 5 6 7
12 13 14 15
6
1
9
10
11
8
16 17
1. Lens
2. Display
3. DC Switch
4. Microphone
5. Left-button
6. Down-button
7. ENTER-button
8. Right-button
9. Mode/Esc
10. Up-button
11. Handle
12. 5-pin DMX out
13. 5-pin DMX in
14. 3-pin DMX out
15. 3-pin DMX in
16. Power supply
17. Fuse
SolaWash 19 LED User Manual
