Zones Protocol; Reduced Protocol - High End Systems SolaWash 19 LED User Manual

Zones Protocol

Channel
1
Pan
2
3
Tilt
4
5 Color Correction
6
Zoom
7
8 Strobe
9
Dim
10
11 MSpeed
12 Control
13 Color Function
14 Red (Zone 1)
15 Green (Zone 1)

Reduced Protocol

Channel
1
Pan
2
3
Tilt
4
5 Color Function
6 Red
7 Green
8 Blue
9 White
10 Color Correction
SolaWash 19 LED User Manual
Function
Function
Channel
16 Blue (Zone 1)
17 White (Zone 1)
18 Red (Zone 2)
19 Green (Zone 2)
20 Blue (Zone 2)
21 White (Zone 2)
22 Red (Zone 3)
23 Green (Zone 3)
24 Blue (Zone 3)
25 White (Zone 3)
26 Red (Zone 4)
27 Green (Zone 4)
28 Blue (Zone 4)
30 White (Zone 4)
30 Indigo Highlighter Function
31 Indigo Highlighter Dim
Channel
11
Zoom
12
13 Strobe
14
Dim
15
16 MSpeed
17 Control
18 Indigo Highlighter Function
19 Indigo Highlighter Dim
CHAPTER 5
DMX Programming
Function
Function
41
