High End Systems SolaWash 19 LED User Manual page 33

Menu Level 2
Playback
Select Prog
Preset
Edit Program
Edit Scenes
Scenes Input
Battery
Note: This menu only appears when you are in battery mode.
SolaWash 19 LED User Manual
Level 3 Option/Setting
DMX Control
Slave 1
Set to Slave Slave 2
Slave 3
Master
Auto Program
Alone
Master
Music Control
Alone
Program 1
...
Prog.Part 1
Program 10
Program 1
...
Prog.Part 2
Program 10
Program 1
...
Prog.Part 3
Program 10
Program Test
Program 1
Step 01=SCxxx
...
...
Step 64=SCxxx
Program 10
End
Pan
...
Indigo Dim
Edit Scene
001
Fade Time
...
Edit Scene
Scene Time
250
Input by Out
x x - x x
Exit Battery
CHAPTER 3
Menu System
Description/Notes
Reverts to playback via console
Assigns slave setting
Assigns auto program mode
Assigns music control mode
Selects program to be run in the
Program part.
Runs the program as edited
Chooses a scene for each step in
the selected program
Save and exit
Allows you to set a DMX value for
any of the 21 parameters. (see
DMX Programming on page 39)
Lets you set a fade time value
from 000–255
Lets you set a scene time from
00.2s–99.9s
Allows you to capture DMX values
for all parameters into a scene
Automated scene recording
Exits the battery mode and shuts
off the display.
21
