CHAPTER 4
Preset Programming

Master and Slave

The following example shows the relationship between scenes, programs and partitions
programmed on the Master and how slave groups are assigned.
• Groups of scenes are edited into Programs 1– 6 on the fixture designated as Master
• Program 2 is assigned to Part 1
• Program 4 is assigned to Part 2
• Program 6 is assigned to Part 3
• Fixtures assigned as Slave 1 playback Part 1
• Fixtures assigned as Slave 2 playback Part 2
• Fixtures assigned as Slave 3 playback Part 3
Part 1
Part 2
Part 3
34
Program 1
Scene 4 Scene 5
Program 2
Scene 11
Scene 10
Program 3
Scene 14 Scene 15
Program 4
Scene 8 Scene 9
Program 5
Scene 20 Scene 21
Program 6
Scene 12 Scene 13
Scene 6 Scene 7
Scene 12 Scene 13
Scene 16 Scene 17
Scene 10
Scene 22 Scene 23
Scene 14 Scene 15
SolaWash 19 LED User Manual
Scene 20
