Preset Menu

Playback Settings

Preset programming requires one fixture to act as the Master. All other SolaWash 19 LED fixtures
on the link running the same user mode can then be set as slaves to playback the Master presets.
Slave fixtures receive all their preset parameter and timing information from the master fixture.
Playback settings designate a fixture as a master or a slave and also allow you to revert from Auto
Programming to DMX control from a console or set a fixture in Master or standalone mode for
audio control.

Automatic Program Run

This Playback option lets you designate a fixture to playback in Standalone mode or as a Master.
Alone is the default setting.
To designate a fixture as a Master:
1. Navigate to and select the Preset menu as shown on page 35.
2. Use the buttons to scroll to Playback menu and press
3. Use the buttons to scroll to Auto Program menu and press
4. Use the
shown in the display.

Set to Slave

After a preset program is defined on a Master fixture, other SolaWash 19 LED fixtures on the
same DMX link can be designated slaves to playback Program Part 1, 2 or 3 as defined on the
Master fixture, see Select Program on page 38.
To designate a fixture as a Slave:
1. Navigate to and select the Preset menu as shown on page 35.
2. Use the
3. Use the buttons to scroll to Set To Slave menu and press
4. Use the buttons to scroll to Slave1, Slave2, or Slave3 option and press
select. Your choice will be shown in the display.

DMX Control

Selecting this option reverts the function from Auto Program (Preset Programming) to DMX
Receive (console control). Selecting this option will take you back to the menu startup screen
where DMX Receive

Music Control

This Playback option lets you designate a fixture to playback scenes based on audio triggers
detected by the internal microphone in stand alone or as a Master. Alone is the default setting.
SolaWash 19 LED User Manual
buttons to scroll to Master and press
buttons to scroll to Playback menu and press
will be displayed as the currently selected function.
Preset Programming
to select.
to select.
to select. Your choice will be
to select.
to select.
CHAPTER 4
to
35
