2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN7
CN8
CN9
CN10
CN11
CN12
CN14
ATX1
SATA1
USB1
LAN1
COM1
COM2
BAT1
SCN1
SCN2
SCN3
SSODIMM1
Board and Pin Assignments
Description
Front Panel Connector
Inverter Connector
LVDS Connector
Audio Connector
Digital I/O Port Connector
Fan Connector
SMBus Connector
USB Wafer Port 2 and 3
HDMI Connector
COM3 and COM4 Connector
SATA Power Connector
VGA Connector
Power Connector
SATA Connector
USB Port 0 and 1
Ethernet Port 1
COM1 Connector
COM2 Connector
CMOS Battery Connector
Half-size PCI-Express Mini Card Connector
Full-size PCI-Express Mini Card Connector
SIM Card Slot
DDR3L SO-DIMM Connector
CAPA848 Capa Board
11
