2.3 Digital PTZ (DPTZ) Operations

This camera has PTZ capability, i.e. digital PTZ (hereafter called "DPTZ"), for wide area monitoring.
STEP1: Click "DPTZ" to show the DPTZ control panel.
STEP2: Select the functions when needed:
FUNCTION ICON
Resolution
Take snapshots
Audio On / Off
Alarm Out
2.4 Event Record Search & Playback
Note: To save more recorded data, it's recommended to use this camera with the compatible NVR.
DESCRIPTION
Select the video resolution for the DPTZ function. Only "VGA" and "QVGA" are available.
--
Click to take a snapshot of the current view on a new window. Right click on the picture and re-save it to the
location you want.
/ Click to switch the audio-in on / off.
Click to force the connected alarm-out device to work. For example, when your alarm device is a buzzer, click
this button and your buzzer will start to sound even if there's no alarm event.
