2.3 Digital PTZ (DPTZ) Operations

This camera has PTZ capability, i.e. digital PTZ (hereafter called "DPTZ"), for wide area monitoring.
STEP1: Click "DPTZ" to show the DPTZ control panel.
FUNCTION
Moving panel
Take snapshots
Zoom in / out
Max. zoom in / out
Normal Size
Scale
ICON DESCRIPTION
When is selected, the moving control panel will be shown to move the picture after zoom-in is
--
performed.
Click to take a snapshot of the current view on a new window. Right click on the picture and re-save it
to the location you want.
/ Click once to enlarge the picture by 1X, and click
Click once to enlarge the picture to the max zoom ratio by 16X, and click
/
picture ratio to 1X.
The current live view size is the same as the selected resolution.
This icon appears only when the selected resolution is 1280 x 720 or above.
Click and hold the movable square on the left bottom corner of the live view to move
This icon appears only when the selected resolution is larger than the current live view size.
5
once to restore the zoom ratio by 1X.
once to restore the
