Avtech DGM5446SVAT Installation

CAMERA INSTALLATION
Step1: Find the star key wrench supplied in the sales package to open the dome
cover.
Step2: Locate where to install this camera and fasten the camera to the ceiling or
wall.
Step3: Loosen the screws as indicated below (if necessary) to adjust the viewing
angle of the camera and fasten the screw to secure the angle.
Step4: (Available only when supported) Find the microSD card slot on the camera
module as indicated below and insert a microSD card.
Step5: Replace the dome cover back. Make sure the rubber ring is well attached
and fastened to ensure the water-proof function works normally.
Package Content

Camera Quick Start
MOTORIZED TYPE
Screws & Waterproof
wall plugs plug kit
Star key
wrench
