Resistance (Ω)
Range Resolution Accuracy Test Voltage Protection
10kΩ (9999Ω) 1Ω 1.0% R ± 3cts <3.0V 600Vrms
DC
Continuity ( )
Buzzer Resolution Test Voltage Protection
<100Ω ± 25Ω 1Ω <3.0V 600Vrms
DC
Analog Output
Range Output Frequency Output Impedance
10mV/A through
A & A 0 to 20kHz @ ± 3db 3kΩ, <50pF
AC DC
front banana jacks
Digital display: 10,000-count 4 digit LCD display (9999 max)
Polarity:
When a negative signal is applied, the symbol appears.
Overload:
If the range is exceeded, the symbol is displayed.
Low Battery Indicator:
is displayed when the voltage supplied by the batteries is lower than the operat-
ing voltage.
Power Supply:
2 batteries - 1.5V type AAA (LR03)
Auto-off:
Automatic shut down after approx 10 minute with over-ride
Sampling:
Approx 2 measurements/second

3.2 Environmental Specifications

Operating Temperature:
32° to 104°F (0° to 40°C), < 80% RH max non-condensing
Storage Temperature:
14° to 140°F (-10° to 60°C), < 70% RH max non-condensing
Altitude: 6000 ft (2000m)
7
AC Clamp-on Meter Model CM605
