CHAPTER 3

SPECIFICATIONS

3.1 Electrical Specifications

Reference Conditions: Accuracy given @ 23°C ± 5°C, 80% RH Max, Conductor centered in jaws, 45-65Hz, No
DC Component.
AC Current ( )
Range Resolution Accuracy Frequency
10A 1mA 2.0% R ± 10cts
50 to 500Hz
80A: 2.0% R ± 10cts
100A 10mA
>80A: 3.5% R ± 10cts
DC Current ( ) - Positive only*
Range Resolution Accuracy
10A 1mA 2.5% R ± 10cts
80A: 2.5% R ± 10cts
100A 10mA
>80A: 4.5% R ± 10cts
AC Volts ( )
Range Resolution Accuracy Impedance Frequency
600V 100mV 1.5% R ± 5cts 10MΩ, <50pF 40 to 500Hz
Overload Protection: 660Vrms
DC Volts ( ) - Positive only*
Range Resolution Accuracy Input Impedance
600V 100mV 1.0% R ± 2cts 10MΩ
Overload Protection: 660Vrms
* For negative measurement, add 2cts to the accuracy
