4.6 Resistance Measurement

Automatic measurement ranges: 0 to 10kΩ
WARNING: When making a resistance measurement, make sure that
the power is off (dead circuit). It is also important that all capacitors
in the measured circuit be fully discharged.
• Turn the rotary switch to the
• Insert the red lead to the red "+" input jack and the black lead to the black
"COM" input jack.
• Bring the test probe tips into contact with the sample under test.
WARNING: If overload "OL" is displayed, the resistance exceeds the
measurement range or the circuit is open.
14
range.
AC Clamp-on Meter Model CM605
